YRT rotary table bearing YRT325

Product Categories

Luo Yang MSR machinery Co.Ltd.

Contact Now

Name: YRT rotary table bearing YRT325
Price: 1388 USD

Add to Cart

Number of retaining screws	Extraction thread hole		1)Number of pitches X angle of pitches	Screw tightening torque	Basic load rating				Limiting speed	3)Bearing frictional torque	weight	bearing type
					axial		radial
					dynamic load	static load	dynamic load	static load
				MA2)	Ｃａ	Coa	Cr	Cor	grease
	G	quantity	×tquantity	Ｎｍ	KN				r/min	Nm	Kg
2	—	—	12×30°	8.5	38	158	28.5	49.5	440	2.5	1.6	YRT50
2	—	—	12×30°	8.5	56	255	42.5	100	530	3	2.4	YRT80
2	M5	3	18×20°	8.5	76.5	415	47.5	120	430	3	4.1	YRT100
2	M8	3	24×15°	14	102	540	52	143	340	7	5.3	YRT120
2	M8	3	36×10°	14	112	630	56	170	320	10	6.2	YRT150
2	M8	3	48×7.5°	14	118	710	69.5	200	280	12	7.7	YRT180
2	M8	3	48×7.5°	14	120	765	81.5	220	260	14	9.7	YRT200
2	M12	3	36×10°	34	160	1060	93	290	200	20	18.3	YRT260
2	M12	3	36×10°	34	275	1930	120	345	170	40	25	YRT325
2	M12	3	48×7.5°	34	300	2280	186	655	140	55	33	YRT395
2	M12	3	48×7.5°	34	355	2800	200	765	120	70	45	YRT460
2	M12	6	48×7.5°	68	490	4250	228	965	80	140	89	YRT580
2	M12	6	48×7.5°	116	1040	8000	490	1800	65	200	170	YRT650
2	M16	6	60×6°	284	1000	8650	455	1730	50	300	253	YRT850
2	M16	6	60×6°	284	1290	11400	530	2040	40	600	312	YRT950
12	M16	6	72×5°	284	1380	12000	620	2650	35	800	375	YRT1030
